2020 Chevy Equinox Engine Power Reduced

The 2020 Chevrolet Equinox, a popular compact SUV, is generally reliable, but like any modern vehicle, it's susceptible to experiencing a "Engine Power Reduced" message. This isn't necessarily a catastrophic failure, but it does indicate a problem detected by the vehicle's sophisticated onboard diagnostic system, and the consequences can range from mildly inconvenient to significantly impacting drivability.

Understanding the "Engine Power Reduced" System

Modern vehicles rely heavily on electronic control units (ECUs), commonly referred to as the engine control module (ECM) or powertrain control module (PCM). These computers constantly monitor a vast array of sensors throughout the engine, transmission, and chassis. When a sensor reports a value outside of its pre-defined parameters, the PCM interprets this as a potential problem. In many cases, to protect critical engine components from damage, the PCM will initiate a "limp mode," which is what triggers the "Engine Power Reduced" message.

The goal of limp mode is to limit the engine's output, reducing stress and preventing further damage. This is typically accomplished by restricting throttle response, limiting engine RPM, and potentially deactivating certain cylinders. The severity of the limitation depends on the nature of the problem detected. Some issues might only cause a slight reduction in power, while others could render the vehicle nearly undriveable.

Common Causes of Reduced Engine Power in the 2020 Equinox

The "Engine Power Reduced" message is a symptom, not the root cause. Diagnosing the underlying problem requires systematic troubleshooting. Here are some of the more frequent culprits in the 2020 Equinox:

Throttle Body Issues

The throttle body controls the amount of air entering the engine. A faulty throttle body, or issues with its associated sensors and actuators, are a common source of this error. Problems can arise from:

Dirty Throttle Body: Carbon buildup and debris can accumulate on the throttle plate, preventing it from opening and closing properly. This disrupts airflow and can trigger the "Engine Power Reduced" message. Cleaning the throttle body is often the first step in diagnosing this issue.
Throttle Position Sensor (TPS) Malfunction: The TPS monitors the throttle plate's position and sends this information to the PCM. A faulty TPS can provide inaccurate readings, leading the PCM to believe the throttle is not responding correctly.
Throttle Actuator Control (TAC) Motor Problems: The TAC motor is responsible for physically opening and closing the throttle plate. If the motor is failing or has a wiring issue, it can't properly control airflow.

Sensor Failures

A multitude of sensors provide crucial information to the PCM. Any sensor reporting incorrect data can potentially trigger the "Engine Power Reduced" message. Common sensor-related culprits include:

Mass Airflow (MAF) Sensor: The MAF sensor measures the amount of air entering the engine. A faulty MAF sensor can cause the engine to run lean or rich, leading to performance problems and the "Engine Power Reduced" warning.
Manifold Absolute Pressure (MAP) Sensor: The MAP sensor measures the pressure in the intake manifold. Problems with the MAP sensor can similarly cause fueling issues and trigger the warning.
Crankshaft Position Sensor (CKP) and Camshaft Position Sensor (CMP): These sensors monitor the position of the crankshaft and camshaft, respectively. They are critical for timing the engine's ignition and fuel injection. A failing CKP or CMP sensor can disrupt timing, leading to significant performance problems and triggering the reduced power mode.
Oxygen (O2) Sensors: O2 sensors monitor the oxygen content in the exhaust stream. Faulty O2 sensors can lead to incorrect fuel trim adjustments, impacting performance and triggering the warning.

Fuel System Problems

Issues within the fuel system can also contribute to reduced engine power:

Fuel Pump Failure: A weak or failing fuel pump cannot provide sufficient fuel pressure to the engine, leading to a lean condition and reduced power.
Clogged Fuel Filter: A clogged fuel filter restricts fuel flow, resulting in similar symptoms to a fuel pump failure.
Fuel Injector Issues: Clogged or faulty fuel injectors can disrupt the fuel delivery process, causing the engine to run poorly and potentially triggering the "Engine Power Reduced" message.

Other Potential Causes

Beyond the aforementioned components, other less common but potential causes include:

Turbocharger Issues (if applicable): The 2020 Equinox offered turbocharged engine options. Problems with the turbocharger, such as a failing wastegate actuator or boost leaks, can lead to reduced power and the warning message.
Catalytic Converter Problems: A clogged or failing catalytic converter restricts exhaust flow, negatively impacting engine performance.
Wiring Harness Issues: Damaged or corroded wiring harnesses can disrupt the signals between sensors, actuators, and the PCM, leading to a variety of problems, including the "Engine Power Reduced" message. This is where a visual inspection can be highly valuable.
PCM Problems: While less common, a faulty PCM can also be the root cause. This is usually diagnosed by ruling out all other potential issues.

Diagnosing the Problem

Diagnosing the "Engine Power Reduced" issue requires a systematic approach:

Read the Diagnostic Trouble Codes (DTCs): Using an OBD-II scanner, retrieve the DTCs stored in the PCM. These codes provide valuable clues about the nature of the problem. Note that a generic code reader may not provide enough detail. A scanner capable of reading manufacturer-specific codes is ideal.
Research the DTCs: Once you have the DTCs, research their meaning and potential causes. Many online resources and repair manuals provide detailed information about specific codes.
Perform Visual Inspection: Carefully inspect the engine compartment for any obvious signs of damage, such as broken wires, loose connectors, vacuum leaks, or fluid leaks.
Test Components: Use a multimeter or other diagnostic tools to test the functionality of suspect components, such as the TPS, MAF sensor, fuel pump, and injectors.
Consult a Repair Manual: A repair manual specific to the 2020 Chevrolet Equinox will provide detailed troubleshooting procedures and component testing instructions.

Tools and Equipment Needed

Diagnosing and repairing the "Engine Power Reduced" issue may require the following tools and equipment:

OBD-II Scanner: To read and clear DTCs.
Multimeter: To test the voltage, resistance, and continuity of electrical components.
Fuel Pressure Tester: To check fuel pump pressure.
Vacuum Gauge: To check for vacuum leaks.
Socket Set and Wrenches: For removing and installing components.
Repair Manual: For detailed troubleshooting procedures and component specifications.

Prevention

While not always preventable, certain maintenance practices can help reduce the likelihood of encountering the "Engine Power Reduced" message:

Regular Maintenance: Follow the manufacturer's recommended maintenance schedule, including oil changes, filter replacements, and spark plug replacements.
Use Quality Fuel: Using high-quality fuel can help prevent carbon buildup in the fuel system and on the throttle body.
Address Issues Promptly: If you notice any unusual engine behavior, such as rough idling or hesitation, address the problem promptly before it escalates.
Regularly Clean the Throttle Body: Periodically cleaning the throttle body can help prevent carbon buildup and ensure proper airflow.

Conclusion

The "Engine Power Reduced" message on a 2020 Chevrolet Equinox indicates a problem that requires investigation. By understanding the potential causes and following a systematic diagnostic approach, you can identify the root cause and restore your vehicle's performance. If you are not comfortable working on your vehicle, it is always best to consult a qualified mechanic. Ignoring the message could lead to more significant and costly repairs down the line.
