Upgrades For Your 240sx With Sr20det

Imagine your heart: a tireless pump circulating lifeblood, constantly adjusting to the demands of your body. Now, picture your SR20DET engine as that heart, and the turbocharger as its performance enhancer. In stock form, it’s a robust and capable powerplant, but like any well-engineered system, it has limitations. When chasing higher horsepower and improved responsiveness, upgrading various components becomes essential. This isn't just about slapping on the biggest turbo you can find; it's about understanding how the engine systems work together and making informed decisions that optimize performance and reliability.

Turbocharger Upgrades: Breathing New Life

Let's start with the heart of the matter: the turbocharger itself. The stock T25 or T28 turbocharger on the SR20DET is a good starting point, providing a decent balance of spool-up and top-end power. However, it quickly becomes a bottleneck as you increase boost and fuel delivery.

How Turbochargers Work

A turbocharger is essentially an air compressor driven by exhaust gases. Hot exhaust from the engine spins a turbine wheel. This turbine is connected to a compressor wheel via a shared shaft. As the turbine spins, it forces the compressor wheel to rotate, drawing in fresh air and compressing it before it enters the engine's intake manifold. This increased air density allows the engine to burn more fuel, resulting in more power. The speed at which the turbocharger 'spools' (reaches its full boost pressure) is influenced by the turbine and compressor wheel size, A/R ratio of the turbine housing, and the overall design.

Upgrading your turbocharger involves selecting a unit that can flow more air at higher pressure ratios. Several factors influence turbocharger selection:

• Compressor Wheel Size: A larger compressor wheel can move more air but typically results in slower spool-up.
• Turbine Wheel Size: Similar to the compressor, a larger turbine wheel can handle more exhaust flow but may negatively affect spool-up.
• A/R Ratio (Area/Radius): This describes the geometry of the turbine housing. A lower A/R ratio will generally result in faster spool-up but may choke exhaust flow at higher RPMs. A higher A/R ratio will allow for better top-end power but may suffer from turbo lag.
• Bearing Type: Ball bearing turbochargers generally spool faster and are more durable than journal bearing turbos.

Examples and Considerations:

• Garrett GT28RS ("Disco Potato"): A popular upgrade offering a good balance of spool-up and power, capable of supporting around 300-350hp. It's a common choice for those seeking a responsive and streetable setup.
• Garrett GTX2867R: Another excellent choice, offering slightly more top-end power than the GT28RS while retaining decent spool characteristics. It utilizes a more advanced compressor wheel design.
• Garrett GT3071R: A larger turbo capable of supporting 400+ hp. However, it will exhibit more lag than the smaller options.
• BorgWarner EFR Series: Known for their advanced features such as Gamma-Ti turbine wheels and integrated wastegate actuators, EFR turbos offer excellent performance and responsiveness.

Pros of Turbo Upgrade: Increased horsepower and torque, improved throttle response (depending on selection). Cons of Turbo Upgrade: Higher cost, potential for increased turbo lag, requires supporting modifications (injectors, fuel pump, ECU tuning).

Fuel System Upgrades: Keeping the Fire Lit

Once you increase the airflow into the engine, you need to supply it with adequate fuel to maintain a proper air/fuel ratio (AFR). The stock fuel system on the SR20DET is limited, especially when running higher boost levels.

How the Fuel System Works

The fuel system consists of several key components: a fuel tank, fuel pump, fuel filter, fuel injectors, and a fuel pressure regulator. The fuel pump draws fuel from the tank and delivers it to the fuel rail, which distributes fuel to the injectors. The fuel pressure regulator maintains a constant fuel pressure in the rail, ensuring consistent fuel delivery. The injectors, controlled by the ECU, spray fuel into the intake ports, where it mixes with air before entering the combustion chamber.

Upgrading the fuel system typically involves replacing the following components:

• Fuel Injectors: Higher flowing injectors are essential to provide the necessary fuel volume for increased power. 550cc or 750cc injectors are common choices for moderately modified SR20DETs.
• Fuel Pump: A higher capacity fuel pump is needed to deliver the increased fuel volume required by the larger injectors. Walbro 255lph or Aeromotive Stealth pumps are popular options.
• Fuel Pressure Regulator: An adjustable fuel pressure regulator allows you to fine-tune the fuel pressure, ensuring optimal AFRs across the RPM range.
• Fuel Rail: An upgraded fuel rail can improve fuel distribution and flow, particularly at higher power levels. While not always necessary for moderate upgrades, it is a good idea for builds aiming for 400+hp.

Examples and Considerations:

• Injector Dynamics ID1050x Injectors: High-quality injectors with excellent atomization and linearity, suitable for a wide range of power levels.
• Injector Dynamics ID1300x Injectors: For even higher power applications, these injectors offer exceptional flow and control.
• Walbro 450lph Fuel Pump: A popular and reliable high-capacity fuel pump capable of supporting significant power gains.
• Aeromotive A1000 Fuel Pressure Regulator: An adjustable fuel pressure regulator that allows for precise fuel pressure control.

Pros of Fuel System Upgrade: Ensures adequate fuel delivery, prevents lean conditions, allows for higher power levels. Cons of Fuel System Upgrade: Higher cost, requires ECU tuning, potential for fuel leaks if not installed properly.

ECU Tuning: The Brain of the Operation

With increased airflow and fuel delivery, the engine's electronic control unit (ECU) needs to be reprogrammed to optimize engine performance. The stock ECU is not designed to handle significant modifications and will likely result in poor performance or even engine damage if left un-tuned.

How the ECU Works

The ECU is the brain of the engine, constantly monitoring various sensors and adjusting engine parameters such as fuel injection timing, ignition timing, and boost pressure to maintain optimal performance and efficiency. It uses pre-programmed maps and algorithms to make these adjustments.

ECU tuning involves modifying these maps to account for the upgraded components. This can be done using aftermarket ECUs or by reflashing the stock ECU with custom software.

Examples and Considerations:

• Nistune: A cost-effective solution for tuning the stock ECU. It allows for real-time tuning and datalogging.
• AEM Infinity: A powerful standalone ECU with advanced features such as traction control, launch control, and flex-fuel support.
• Haltech Elite Series: Another popular standalone ECU offering a wide range of features and tuning options.

Pros of ECU Tuning: Optimizes engine performance, improves throttle response, increases power, enhances fuel efficiency, prevents engine damage. Cons of ECU Tuning: Requires specialized knowledge and equipment, potential for engine damage if not done correctly.

Intercooler Upgrades: Keeping Things Cool

As air is compressed by the turbocharger, it heats up. Hot air is less dense than cold air, which reduces the amount of oxygen available for combustion. An intercooler is used to cool the compressed air before it enters the engine, increasing its density and improving performance.

How Intercoolers Work

An intercooler is essentially a heat exchanger that cools the compressed air by dissipating heat to the surrounding air. It typically consists of a core with fins and tubes, similar to a radiator. Compressed air flows through the tubes, while ambient air flows over the fins, drawing heat away from the compressed air.

Intercoolers come in two main types: air-to-air and air-to-water.

• Air-to-Air Intercoolers: These are the most common type, using ambient air to cool the compressed air. They are relatively simple and cost-effective.
• Air-to-Water Intercoolers: These use water to cool the compressed air, which is then cooled by a radiator. They are more efficient than air-to-air intercoolers but are also more complex and expensive.

An upgraded intercooler will improve cooling efficiency, resulting in denser air and increased power. A larger intercooler core and improved fin design will enhance cooling capacity.

Examples and Considerations:

• Front Mount Intercooler (FMIC): Replaces the stock side mount intercooler with a larger core mounted in front of the radiator. Offers significantly improved cooling capacity.
• Side Mount Intercooler (SMIC) Upgrade: Replaces the stock SMIC with a larger and more efficient unit. A good option for those who want to retain the stock look.

Pros of Intercooler Upgrade: Increases air density, improves power, reduces engine knock, enhances reliability. Cons of Intercooler Upgrade: Can increase turbo lag (especially with large FMICs), requires modification to the bumper or chassis.

Exhaust System Upgrades: Letting it Breathe

A restrictive exhaust system can hinder performance by creating backpressure, which reduces engine efficiency. Upgrading the exhaust system allows the engine to breathe more freely, resulting in increased power and improved throttle response.

How Exhaust Systems Work

The exhaust system is responsible for carrying exhaust gases away from the engine. It typically consists of an exhaust manifold, downpipe, catalytic converter, and cat-back exhaust system. The exhaust manifold collects exhaust gases from the cylinders and directs them into the downpipe. The downpipe connects the exhaust manifold to the catalytic converter, which reduces harmful emissions. The cat-back exhaust system consists of the piping and muffler that run from the catalytic converter to the rear of the car.

Upgrading the exhaust system typically involves replacing the downpipe and cat-back exhaust system with larger diameter piping and less restrictive components. Removing the catalytic converter (though not legal for street use in many areas) can also improve exhaust flow.

Examples and Considerations:

• 3" Downpipe: A larger diameter downpipe will reduce backpressure and improve exhaust flow.
• 3" Cat-Back Exhaust System: A larger diameter cat-back exhaust system will further reduce backpressure and improve exhaust flow.

Pros of Exhaust System Upgrade: Reduces backpressure, improves exhaust flow, increases power, improves throttle response. Cons of Exhaust System Upgrade: Can increase noise levels, may require modification to the chassis, may not be legal for street use in some areas.

Real-World Considerations and Recommendations

Upgrading your SR20DET is a journey, not a race. Each modification should be carefully considered, and its impact on other components should be understood. Don't simply chase the highest horsepower numbers without addressing supporting systems. For a reliable and responsive street car, a GT28RS or GTX2867R turbo, paired with 550cc injectors, a Walbro 255lph fuel pump, and a Nistune ECU, is a fantastic starting point. Focus on a proper tune and reliable components. For those aiming for higher power levels, a larger turbo, upgraded fuel system, and standalone ECU are essential, but remember that this will likely come at the expense of some streetability. Ultimately, the best upgrades for your SR20DET will depend on your individual goals, budget, and intended use of the car. Before making any modifications, research thoroughly and consult with experienced tuners and mechanics.
